GW Instek PSW-1080H668 Triple-channel switching DC Power supply, 250/250/800V, 1080W

The GW Instek PSW-1080H668 is a powerful triple-channel programmable switching DC power supply that delivers high performance, safety, and flexibility in advanced test environments. Featuring three independent outputs rated at 250V, 250V, and 800V, with a total capacity of 1080W, this unit is well-suited for applications that require a mix of medium-voltage and high-voltage outputs within one instrument.

Supporting independent, series, and parallel operation, the PSW-1080H668 enables users to configure voltage and current combinations for a wide variety of test scenarios. Its programmable sequencing and multi-channel synchronization simplify complex setups, while the large LCD interface ensures precise monitoring and user-friendly operation. Remote control is enabled via USB, LAN, RS232, and optional GPIB, making it suitable for both manual and automated testing environments.

Safety features including Over Voltage Protection (OVP), Over Current Protection (OCP), Over Temperature Protection (OTP), and reliable CC/CV operation protect both the instrument and connected devices.

Key Features:

• Triple outputs: 250V / 250V / 800V

• Total power capacity: 1080W

• Independent, series, and parallel channel operation

• High-resolution LCD display with programmable sequencing

• Remote interfaces: USB, LAN, RS232, optional GPIB

• Safety protections: OVP, OCP, OTP, CC/CV modes

Compatible Applications:

• High-voltage electronics testing

• Power electronics and industrial validation

• Renewable energy and energy storage system research

• Academic and research laboratories requiring versatile outputs

Included Accessories:

• AC power cord

• USB interface cable

• Quick start manual

• Software utilities CD (where applicable)

Compliance:

• ISO and GLP compliant

• CE certified to international safety standards

Benefits for Lab Users:

• Combines medium (250V) and high-voltage (800V) outputs in one instrument

• Multi-channel design reduces the need for multiple power supplies

• Remote programmability improves efficiency and automation

• Safety protections ensure consistent, reliable, and secure operation
