GW Instek PSW-1080H888 Triple-channel switching DC Power supply, 800/800/800V, 1080W

The GW Instek PSW-1080H888 is a top-tier triple-channel programmable switching DC power supply built to meet the needs of high-voltage applications. With three independent 800V outputs and a maximum output power of 1080W, it is the ideal solution for power electronics validation, renewable energy system research, and industrial high-voltage testing.

Each channel can operate independently, in series, or in parallel, offering unmatched versatility for configuring voltage and current outputs. The high-resolution LCD display provides real-time monitoring and intuitive control, while programmable sequencing and remote control features enhance automation. Connectivity options include USB, LAN, RS232, and optional GPIB, making integration into automated test environments seamless. Built-in safety protections — OVP, OCP, OTP, and CC/CV operation — ensure safe operation even under demanding test conditions.

Key Features:

• Triple outputs: 800V / 800V / 800V

• Total output: 1080W

• Independent, series, and parallel operation modes

• High-resolution LCD display with programmable sequencing

• Remote connectivity: USB, LAN, RS232, optional GPIB

• Safety protections: OVP, OCP, OTP, CC/CV operation

Compatibility:

• High-voltage electronics and circuit testing

• Solar inverter and renewable energy validation

• Battery systems and energy storage research

• Advanced R&D and industrial laboratories

Included Accessories:

• AC power cord

• USB interface cable

• Quick start manual

• Software utilities CD (where applicable)

Compliance:

• ISO and GLP compliant for laboratory operations

• CE certified to international safety and performance standards

Benefits for Lab Users:

• Triple high-voltage outputs (800V each) for demanding applications

• Consolidates multiple high-voltage supplies into one unit

• Safety-focused protections safeguard devices and users

• Programmable sequencing and remote control improve workflow efficiency
