SMC MENTOR 12 (3V-6I)

The SMC MENTOR 12 (3V-6I) is a high-performance secondary injection test system designed for comprehensive testing of protection relays and substation automation devices. Featuring 3 voltage outputs and 6 current outputs, this configuration is ideal for three-phase current testing, differential relay schemes, and end-to-end system validation. Built for portability and precision, the MENTOR 12 (3V-6I) supports manual and automated testing via user-friendly software and interfaces, making it an essential tool for electrical utilities, maintenance teams, and commissioning engineers in the field.

Specifications:

Voltage Outputs: 3 independent channels

Current Outputs: 6 independent channels

Voltage Range: Up to 300 V (per channel, model-dependent)

Current Range: Up to 30 A (per channel, model-dependent)

Output Accuracy: High precision for protection system calibration

Operation Modes: Manual, semi-auto, and automatic test sequences

Interfaces: USB, Ethernet, optional Wi-Fi

Software: SMC control and reporting software compatible

Design: Rugged, field-portable casing

Applications: Differential relay testing, substation commissioning, protection relay calibration, three-phase system testing
